Anchor Brakes

Anchor brakes are used as shock absorbers in rigging, although I've seldom seen them used in ordinary situations. They can also be used to rig dynamic cow’s tails.

The MSR Auto Belayer was marketed as an autobelayer, not an anchor brake, but the device and application is so similar to other dissipators that I included it here.

ID	Device ↓	Description	Acquired	Weight ↓	Height ↓	Width ↓	Thickness ↓	Std. volume ↓
3760	AustriAlpin	Milled Al plate, hard anodized, dual rope, 3-12 mm. rope holes per side, belay slot, 20 mm. eye	On Rope 1, 2000	113	118	69	10	81
709	Camp Dissipatore	Forged Al, unfinished, 5-11 mm. & 1-10 mm. rope holes, 2-12 mm. eyes	Eiselin Sport, 1997	57	97	45	9	39
2868	Cassin, Version A	Forged Al, soft anodized,six 12-mm rope holes, oval eye	Noco Gear, 2021	58	88	45	9	36
2873	Cassin, Version B	Forged Al, soft anodized,six 12-mm rope holes, oval eye	Noco Gear, 2021	58	88	45	9	35
727	Climbing Technology	Forged Al, Anodized, 5-12 mm. rope holes, L-shaped eye	Inner Mountain Outfitters, 1999	51	90	49	9	40
630	Grivel ABA	Drilled Al plate, unfinished, 5-10 mm. rope holes, 12 mm. eye.	Repetto Sport, 1982	70	71	50	10	36
629	Kong-Bonaiti Kisa, Version A	Forged Al, unfinished, 5-12 mm. & 1-9 mm. rope holes, 23 mm. eye	1982	58	107	44	9	42
2883 3792	Kong-Bonaiti Kisa, Version B	Forged Al, soft anodized, 5-11.4 mm. & 1-9 mm. rope holes, 24.5 mm. eye	Kelly Byrne, 2021 Kelley Deem, 2022	61	108	45	9	45
848 871 1661 1674 2844	Kong Kisa	Forged Al, hard anodized 5-11 mm. & 1-9 mm. rope holes, teardrop eye	The Outdoor Store, 2007 Mountainland Outdoor, 2007 Paolo Favero, 2009 Barrabés.com, 2009 Marco Bonaiti / Kong (2), 2021	62	105	44	9	41
877 2628	MSR Auto Belayer, Version A	Milled Al plate, soft anodized, adjustment screw	Bill Ivanoff, 2007 Bob Thrun Collection, 2017	93	92	50	16	73
1880	MSR Auto Belayer, Version B	Milled Al plate, soft anodized, adjustment screw	CarolJo Rushin-Elron, 2016	90	94	51	16	76
3723	MSR Auto Belayer, Version C	Milled Al plate, soft anodized, adjustment screw	Todd R Lindell, 2022	80	79	51	16	64
3778	MSR Auto Belayer, Version D	Milled Al plate, unfinished, adjustment screw	L. E. Bibb, 2022	80	79	51	16	63
1762	Singing Rock	Forged Al, Anodized, 5-12 mm. rope holes, L-shaped eye	Tom Furey, 2012	52	90	48	9	39
683	Stubai Klettersteigbremse	Milled Al plate, hard anodized, dual rope, 3-12 mm. rope holes per side, belay slot, 20 mm. eye	Speleoshoppe, 1995	110	118	69	10	81
1662	Unknown	Forged Al, Anodized, 5-19 mm. rope holes, 24 mm. eye	Paolo Favero, 2009	60	98	45	9	41
